The latest addition to Tamiya's 1/14 scale R/C Tractor Truck series is the MAN TGX 26.540 6x4 XLX. This impressive truck, which made its debut at the 2007 European Transport Road Show in Amsterdam, was the winner of the 2008 Truck of the Year award. It features two rear axles which assist in the carrying of heavy loads over long distances. It is powered by an in-line 6 cylinder 12.4 liter turbocharged diesel engine which meets the stringent Euro 5 emissions standards to make it more environmentally friendly.
Specifications
Scale 1:14
Length: 526mm, Width: 193mm, Wheelbase 237 + 103mm
The latest addition to Tamiya's 1/14 scale R/C Tractor Truck series is the MAN TGX 26.540 6x4 XLX. This impressive truck, which made its debut at the 2007 European Transport Road Show in Amsterdam, was the winner of the 2008 Truck of the Year award. It features two rear axles which assist in the carrying of heavy loads over long distances. It is powered by an in-line 6 cylinder 12.4 liter turbocharged diesel engine which meets the stringent Euro 5 emissions standards to make it more environmentally friendly.
Specification
Length: 526mm, Width: 193mm, Height: 301mm, Weight (without optional parts): Approx. 3.8kg
Wheelbase: 237+103mm
Tread: 156mm (Front), 138mm (Rear, Double Tire)
Chassis: Aluminum & Polycarbonate Resin Ladder Frame
Suspension: Front/Rear Leaf Springs
Caster Angle (Front/Rear): 0°/0°
Camber Angle (Front/Rear): 0°
Toe Angle: 0°(Front & Rear)
Dampers: Aluminum Dummy Dampers (Front & Rear)
Drivetrain: Rear Double Axle Drive
Transmission: 3-gear transmission (gear shifting operated via transmitter)
Gear Ratio: (1st Gear) 32.49:1, (2nd Gear) 17.76:1, (3rd Gear) 10.66:1
Diff. Gear: 3-bevel diff
Motor: Type 540
Tire Width: 22mm (Front & Rear)
Tire Diameter: 83mm (Front & Rear)
